Home

Details

Written by: sam

Category: 電腦相關

Published: 03 September 2026

Hits: 3

來把預設需多次加、解密封包的flannel，更換一下成host-gw
因為我的環境剛好就有WG，所以就沒有使用內建的host-gw, 不然就更加快速和方便

不過最好是開始安怖建環境就先規劃好，而不是像我中途更換，因為會中斷業務

kubectl get nodes -o jsonpath='{range .items[*]}{.metadata.name}{"\n"}{.metadata.annotations}{"\n\n"}{end}' | grep flannel

{"alpha.kubernetes.io/provided-node-ip":"10.99.99.3","flannel.alpha.coreos.com/backend-data":"null","flannel.alpha.coreos.com/backend-type":"host-gw","flannel.alpha.coreos.com/kube-subnet-manager":"true","flannel.alpha.coreos.com/public-ip":"10.99.99.3","k3s.io/hostname":"chunk01","k3s.io/internal-ip":"10.99.99.3","k3s.io/node-args":"[\"server\",\"--token\",\"********\",\"--flannel-backend\",\"host-gw\",\"--flannel-iface\",\"wg0\",\"--node-ip\",\"10.99.99.3\",\"--bind-address\",\"10.99.99.3\",\"--kubelet-arg\",\"allowed-unsafe-sysctls=net.ipv4.ip_forward,net.ipv6.conf.all.forwarding,net.core.somaxconn,net.ipv4.tcp_max_syn_backlog\"]","k3s.io/node-config-hash":"IOSXWZITEQ256E6O2AAIPGV5WYEFL3IEWCNHDPOC1SBYOC5EDV3RA====","k3s.io/node-env":"{}","node.alpha.kubernetes.io/ttl":"0","volumes.kubernetes.io/controller-managed-attach-detach":"true"}
{"alpha.kubernetes.io/provided-node-ip":"10.99.99.1","flannel.alpha.coreos.com/backend-data":"null","flannel.alpha.coreos.com/backend-type":"host-gw","flannel.alpha.coreos.com/kube-subnet-manager":"true","flannel.alpha.coreos.com/public-ip":"192.227.175.204","k3s.io/hostname":"linux.53247a.com","k3s.io/internal-ip":"10.99.99.1","k3s.io/node-args":"[\"agent\",\"--server\",\"https://10.99.99.3:6443\",\"--token\",\"********\",\"--kubelet-arg\",\"allowed-unsafe-sysctls=net.ipv4.ip_forward,net.ipv6.conf.all.forwarding,net.core.somaxconn,net.ipv4.tcp_max_syn_backlog\",\"--node-ip\",\"10.99.99.1\"]","k3s.io/node-config-hash":"XMULZZBZM75HQFXUD6ATULQCYUYPOWQMMPG2AZH34ZSGTIEK35V6A====","k3s.io/node-env":"{\"K3S_TOKEN\":\"********\",\"K3S_URL\":\"https://191.96.11.162:6443\"}","node.alpha.kubernetes.io/ttl":"0","volumes.kubernetes.io/controller-managed-attach-detach":"true"}
{"alpha.kubernetes.io/provided-node-ip":"10.99.99.2","flannel.alpha.coreos.com/backend-data":"null","flannel.alpha.coreos.com/backend-type":"host-gw","flannel.alpha.coreos.com/kube-subnet-manager":"true","flannel.alpha.coreos.com/public-ip":"107.173.182.29","k3s.io/hostname":"linux.53247b.com","k3s.io/internal-ip":"10.99.99.2","k3s.io/node-args":"[\"agent\",\"--server\",\"https://10.99.99.3:6443\",\"--token\",\"********\",\"--kubelet-arg\",\"allowed-unsafe-sysctls=net.ipv4.ip_forward,net.ipv6.conf.all.forwarding,net.core.somaxconn,net.ipv4.tcp_max_syn_backlog\",\"--node-ip\",\"10.99.99.2\"]","k3s.io/node-config-hash":"6HAIZYGWKSMJKPEWE2CMRZTEEE2ZXYLE6CEGC2NQJDUDUMH35XONA====","k3s.io/node-env":"{\"K3S_TOKEN\":\"********\",\"K3S_URL\":\"https://191.96.11.162:6443\"}","node.alpha.kubernetes.io/ttl":"0","volumes.kubernetes.io/controller-managed-attach-detach":"true"}

Read more: k3s k8s -3 flannel

Details

Written by: sam

Category: 電腦相關

Published: 30 August 2026

Hits: 19

這個是非常方便可以HPA自動橫向縮、放的功能

完成圖

 kubectl get hpa -w
NAME                       REFERENCE        TARGETS       MINPODS   MAXPODS   REPLICAS   AGE
keda-hpa-app-keda-scaler   Deployment/app   0/120 (avg)   2         4         2          13m
keda-hpa-app-keda-scaler   Deployment/app   22m/120 (avg)   2         4         2          16m
keda-hpa-app-keda-scaler   Deployment/app   0/120 (avg)     2         4         2          17m
keda-hpa-app-keda-scaler   Deployment/app   22m/120 (avg)   2         4         2          18m
keda-hpa-app-keda-scaler   Deployment/app   0/120 (avg)     2         4         2          19m
keda-hpa-app-keda-scaler   Deployment/app   22m/120 (avg)   2         4         2          19m
keda-hpa-app-keda-scaler   Deployment/app   0/120 (avg)     2         4         2          20m
keda-hpa-app-keda-scaler   Deployment/app   45m/120 (avg)   2         4         2          23m
keda-hpa-app-keda-scaler   Deployment/app   0/120 (avg)     2         4         2          24m
keda-hpa-app-keda-scaler   Deployment/app   22m/120 (avg)   2         4         2          25m
keda-hpa-app-keda-scaler   Deployment/app   67m/120 (avg)   2         4         2          25m

Read more: k3s k8s -2 Keda

Details

Written by: sam

Category: 電腦相關

Published: 22 August 2026

Hits: 68

今天來記錄地端 Gitea, 目的：不倚賴雲端，有更好安全性。寫得差的程式比較不會被發現…

root@chunk03:~# mkdir -p /var/lib/gitea

root@chunk03:~# mkdir -p /var/lib/local-registry

root@chunk03:~# mkdir -p /var/lib/gitea-runner

root@chunk03:~# chown -R 1000:1000 /var/lib/gitea /var/lib/gitea-runner

因為我這台有K3s master, 純管沒做事，負載很低，所以直接拿來用(正常最好分開

registry.yaml

Read more: k3s k8s -1 gitea
